Reverberi M4201 TASMAC Suction Spotting Table with Stain Removal Guns
Suction spotting table with stain removal guns
Specification
- Model
- M4201 (TASMAC)
- Manufacturer
- Reverberi s.r.l., Italy
- Type
- Suction spotting table with stain removal guns (no compressor required)
- Power supply
- 220/380 V / 3 phase / 50 Hz
- Vacuum motor power
- 0.25 kW
- Air consumption
- 200 Nl/min
- Steam inlet
- 3/8 inch
- Return outlet
- 1/2 inch
- Steam consumption
- 2 to 3 kg/h
- Board dimensions
- 850 x 270 x 160 mm
- Arm dimensions
- 390 x 100 x 65 mm
- Machine dimensions
- 1500 x 780 x 910 mm
- Net weight
- 115 kg
- Gross weight (crated)
- 185 kg
- Package dimensions
- 1440 x 630 x 1020 mm
- Package volume
- 0.92 m³
- Spotting guns included
- 2 (water and solvent)
No downloads are published for this model. Data sheets, operator manuals and dimension drawings are available on request.
The Reverberi M4201 TASMAC is a professional suction spotting table designed for dry cleaners and garment care operations requiring efficient stain removal and spotting capabilities. Equipped with vacuum suction board and arm, steam connection, and two professional spotting guns (water and solvent), the M4201 provides a complete spotting station for treating stains on garments before or after cleaning. The vacuum system removes moisture and solvent vapours during spotting work, protecting operators and ensuring efficient stain treatment. Operating on 220/380V three-phase power without the need for an external air compressor, this professional spotting table is manufactured by Reverberi s.r.l. in Italy and supplied in South Africa by Unicorp for commercial dry cleaning operations.
The Reverberi M4201 TASMAC spotting table combines a vacuum suction work surface with professional spotting guns to provide efficient stain removal in dry cleaning operations. The perforated work board and articulated arm both feature vacuum suction to remove moisture, solvent vapours, and chemical fumes during spotting work. Two professional spotting guns are included: one for water-based spotting agents and one for solvent-based chemicals, providing complete flexibility for treating different stain types. The steam connection allows operators to use steam for loosening stubborn stains and assisting with chemical penetration. The vacuum motor removes airborne solvent vapours and moisture, protecting operator health and maintaining a safe working environment. The spotting table operates on three-phase 220/380V power and does not require an external air compressor, simplifying installation and operation.
Genuine Reverberi spare parts for the M4201 TASMAC spotting table are available through Unicorp, with technical support across South Africa to ensure long-term reliability and optimal performance of your professional spotting equipment. Unicorp maintains stock of common Reverberi components including spotting gun assemblies, vacuum motor parts, steam valves, and work surface covers for ongoing maintenance and repairs.
A spotting table is used to treat individual stains on garments before or after the main cleaning process. Using specialised spotting chemicals, steam, and mechanical action, operators can remove stubborn stains such as ink, grease, wine, coffee, and protein-based stains that may not be fully removed during the standard dry cleaning cycle. The vacuum suction removes chemical vapours and moisture during the spotting process, protecting operator health.
Price and availability: Reverberi M4201 TASMAC Suction Spotting Table with Stain Removal Guns
Tell us what you are running and we will confirm the price, the lead time and whether this is the right model for it.
Answers before you enquire
- What is a spotting table used for in dry cleaning?
- A spotting table is used to treat individual stains on garments before or after the main cleaning process. Using specialised spotting chemicals, steam, and mechanical action, operators can remove stubborn stains such as ink, grease, wine, coffee, and protein-based stains that may not be fully removed during the standard dry cleaning cycle. The vacuum suction removes chemical vapours and moisture during the spotting process, protecting operator health.
- Why does the M4201 have two spotting guns?
- The two spotting guns allow operators to use both water-based and solvent-based spotting agents without the need to change guns or contaminate chemicals. Different stain types require different spotting agents: water-based spotting chemicals are used for tannin stains, sugars, and water-soluble stains, while solvent-based spotting agents are used for oil, grease, and petroleum-based stains. Having both guns available increases efficiency and spotting success rates.
- Does the M4201 require an external air compressor?
- No. The M4201 TASMAC operates without an external air compressor. The integrated 0.25 kW vacuum motor provides the suction required for the work board and articulated arm. This simplifies installation and reduces the space and equipment requirements for the spotting station.
- What electrical supply does the M4201 require?
- The M4201 requires 220/380V three-phase electrical supply at 50 Hz. This is standard industrial three-phase power that is typically available in commercial dry cleaning facilities. Unicorp can advise on electrical installation requirements and coordinate with your electrician to ensure correct connection.
- Does Unicorp provide installation and training?
- Yes. Unicorp provides delivery coordination, installation support, and operator training for Reverberi spotting tables across South Africa. Our team can advise on correct installation, steam supply connection, electrical requirements, and demonstrate proper spotting techniques and chemical usage to ensure your equipment delivers effective stain removal results from day one.
